Electrical connection specification
Supply voltage 3.8 - 20 VDC
Consumption 8 mA max.
Signal voltage Taken from Ground.
Leakage current 10μ A max.
Signal load 20mA max.
Signal Square wave
Duty cycle 50%
Technical specification
Flow rate 0.070-1.200 liter/min
Measuring accuracy ± 5 %
Operating fluid Water
Operating temperature -10 to 65 °C
Operating pressure -1 to 0.3 bar
Mounting Horizontal position
Connector ?6.0 mm
